The EuroWood module is intended for design and verification of single-branch, planar and spatial timber structures with rectangular cross-sections, according to PN-EN 1995-1-1 Eurocode 5, in the ArCADia-RAMA program, in the unidirectional and bidirectional stress state, including the torsional moment. The program checks the load capacity and deflections taking into account rheological influences for solid and glued laminated timber elements of rectangular cross-sections. Depending on the internal forces occurring, the following verifications of the ultimate and the serviceability limit states can be carried out in the program:

• Checking flexural stability in the bending state.

• Checking two-way bending with compression.

• Checking compression with two-way bending.

• Checking two-way bending.

• Checking two-way bending with tension.

• Checking axial compression.

• Checking axial tension.

• Checking one and two-way shear.

• Checking torsion with shear.

• Checking the permissible relative deflection and displacement taking into account rheological influences (creep and humidity).

All of the above conditions are checked in accordance with PN-EN 1995-1-1 Eurocode5. The program is made in the form of an integrated installation, built into the program for static calculations ArCADia-RAMA.
